CLT209 Steel Water Tank | 209,833L
| Standard Features | COLORBOND® or ZINCALUME® steel walls & roof, Roof trusses, hot-dipped galvanised, Australian made polyfabric liner, 1 x 2” outlet and valve, 1 x 4” overflow, 1 x leaf basket OR 50mm inlet, 1 x lockable manhole, Bolt fascia |
|---|---|
| Material | choice of Colorbond® or Zincalume® |
| Capacity | 209,833 litres |
| Height | 2.2 metres |
| Diameter | 11.02 metres |
| Pad Size | Width | 13.02 m3 |
| Pad Size | Depth | 150 mm |
| On Install | Sand | 28 m3 |
| On Install | Water | 10,000 litres |
| After Install | Aggregate | 1.8 m3 |
| Optional Add-Ons | Additional 50mm inlet, Additional 50mm outlet with valve, Custom inlets and outlet, Water level indicator, External / internal ladder, Dust & vermin proofing, Valve with Storz coupling for fire outlet |
The CLT209 tank is designed for large-scale operations requiring a substantial and dependable water supply. Ideal for extensive irrigation, industrial sites, and emergency preparedness.
Additional information
| Standard Features | COLORBOND® or ZINCALUME® steel walls & roof, Roof trusses, hot-dipped galvanised, Australian made polyfabric liner, 1 x 2” outlet and valve, 1 x 4” overflow, 1 x leaf basket OR 50mm inlet, 1 x lockable manhole, Bolt fascia |
|---|---|
| Material | choice of Colorbond® or Zincalume® |
| Capacity | 209,833 litres |
| Height | 2.2 metres |
| Diameter | 11.02 metres |
| Pad Size | Width | 13.02 m3 |
| Pad Size | Depth | 150 mm |
| On Install | Sand | 28 m3 |
| On Install | Water | 10,000 litres |
| After Install | Aggregate | 1.8 m3 |
| Optional Add-Ons | Additional 50mm inlet, Additional 50mm outlet with valve, Custom inlets and outlet, Water level indicator, External / internal ladder, Dust & vermin proofing, Valve with Storz coupling for fire outlet |
