CLT140 Steel Water Tank | 140,580L
| Standard Features | COLORBOND® or ZINCALUME® steel walls & roof, Roof trusses, hot-dipped galvanised, Australian made polyfabric liner, 1 x 2” outlet and valve, 1 x 4” overflow, 1 x leaf basket OR 50mm inlet, 1 x lockable manhole, Bolt fascia |
|---|---|
| Material | choice of Colorbond® or Zincalume® |
| Capacity | 140,580 litres |
| Height | 2.2 metres |
| Diameter | 9.02 metres |
| Pad Size | Width | 11.02 metres |
| Pad Size | Depth | 150 mm |
| On Install | Sand | 13.5 m3 |
| On Install | Water | 6,000 litres |
| After Install | Aggregate | 1.5 m3 |
| Optional Add-Ons | Additional 50mm inlet, Additional 50mm outlet with valve, Water level indicator, External/Internal ladder, Dust & vermin proofing, Valve with Storz coupling for fire outlet.
Custom sized inlets or outlets in sizes 3, 4 and 6 inches. Please contact for prices. |
Offering 140,580 litres of storage, the CLT140 tank is suited for large-scale farming, industrial applications, and fire safety reserves. A robust investment for water security.
Additional information
| Standard Features | COLORBOND® or ZINCALUME® steel walls & roof, Roof trusses, hot-dipped galvanised, Australian made polyfabric liner, 1 x 2” outlet and valve, 1 x 4” overflow, 1 x leaf basket OR 50mm inlet, 1 x lockable manhole, Bolt fascia |
|---|---|
| Material | choice of Colorbond® or Zincalume® |
| Capacity | 140,580 litres |
| Height | 2.2 metres |
| Diameter | 9.02 metres |
| Pad Size | Width | 11.02 metres |
| Pad Size | Depth | 150 mm |
| On Install | Sand | 13.5 m3 |
| On Install | Water | 6,000 litres |
| After Install | Aggregate | 1.5 m3 |
| Optional Add-Ons | Additional 50mm inlet, Additional 50mm outlet with valve, Water level indicator, External/Internal ladder, Dust & vermin proofing, Valve with Storz coupling for fire outlet. Custom sized inlets or outlets in sizes 3, 4 and 6 inches. Please contact for prices. |
